Fast delivery within 72 Hours

Q1656-DLE

Name: Q1656-DLE
Brand: Axis
SKU: 02420-001
Availability: OutOfStock

£0.00

Excl.VAT

SKU: 02420-001 Category: IP Cameras Brand: Axis

Out of stock

Add to compare

Add to wishlist

Add to compare

Add to wishlist

Shipping & Delivery

Standard delivery

Our courier will deliver to the specified address

3-4 Days

From £9.95

Express delivery

All heavy items above 25kg will be charged shipping cost as per actual

1-2 Days

From £14.95

Q1656-DLE

This unique device fuses two powerful technologies to deliver next-level detection and visualization for reliable wide-area intrusion protection 24/7. Video and radar analytics come together in AXIS Object Analytics to provide precise localization and object classification powered by deep learning and distance and speed measurements based on an object’s radar signature and movement characteristics. By default, our intelligent fusion system handles notifications in the most advantageous way depending on what best suits the circumstances. Or, if you prefer, you can choose between minimizing false notifications or never missing a thing.

Audio

Audio detection	Yes
Audio formats supported	AAC-LC, ADPCM, G.711, G.726, LPCM, OPUS, PCM
Audio system full duplex	Yes

Camera

Camera pan control	Yes
Camera shutter speed	1/47500 - 1 s
Camera tilt control	Yes
Minimum illumination	0.05 lx

Design

Form factor	Box
IK code	IK08
International Protection (IP) code	IP66
LED indicators	Yes
Mounting type	Ceiling/wall
Product colour	White

Image sensor

Number of sensors	1
Optical sensor size	1/1.8 "
Progressive scan	Yes
Sensor type	CMOS

Lens system

Auto focus	Yes
Focal length range	3.9 - 10 mm
Normal focusing range	0.5 m
Number of lenses	4
Optical zoom	2.5 x
Zoom capability	Yes

Network

Ethernet LAN	Yes
Networking standards	IEEE 802.1x, IEEE 802.3af, IEEE 802.3at
Quality of Service (QoS) support	Yes

Night vision

Infra-red wavelength	850 nm
LED type	IR
Night vision	Yes
Night vision distance	50 m

Operational conditions

Operating relative humidity (H-H)	10 - 100 %
Operating temperature (T-T)	-40 - 60 °C
Storage relative humidity (H-H)	5 - 95 %
Storage temperature (T-T)	-40 - 65 °C

Packaging content

Number of cameras	1

Performance

Alarm input/output	Yes
Connectivity technology	Wired
Day/night mode	Yes
Infrared (IR) cut-off filter	Yes
Languages support	English, French, German, Italian, Japanese, Korean, Polish, Portuguese, Russian, Simplified Chinese, Spanish, Traditional Chinese
Number of languages	12
PTZ control	Yes
PTZ modes	Digital PTZ
PTZ protocols	Pelco-D
Placement supported	Outdoor
Type	IP security camera
Wide Dynamic Range (WDR)	Yes

Ports & interfaces

Ethernet LAN (RJ-45) ports	1
Terminal block port	Yes

Power

AC input voltage	10 - 28 V
Power consumption (max)	25.5 W
Power consumption (typical)	9.5 W
Power source type	PoE

Security

Alert notification type	E-mail, Text alert message
Digest authentication	Yes
HTTPS encryption	Yes
IP address filtering	Yes
Password protection	Yes
Pixel counter	Yes
Security algorithms	EAP-TLS
Video motion detection	Yes

Storage

Card reader integrated	Yes
Compatible memory cards	MicroSD (TransFlash), MicroSDHC, MicroSDXC, SD
Flash memory	8194 MB
Internal memory	2048 MB

Technical details

Doesn't contain	BFR, PVC
Suitable for outdoor use	Yes

Vendor information

Brand Name	Axis
Warranty	5 Year(s)

Video

Bit rate	Configurable bit rate
Flip & mirror	Yes
Frame rate	60 fps
Gain control type	Auto
Image quality adjustment	Brightness, Contrast, Saturation
Maximum resolution	2688 x 1512 pixels
Noise reduction	Yes
Privacy masking	Yes
Text caption overlay	Yes
Total megapixels	4 MP
Video compression formats	H.264, H.265
Video recording	Yes
Video streaming	Yes
