Flexible, 8-port 2.5 GbE switch with a 10 GbE RJ45/SFP+ combination uplink port that can be powered with a USB-C or PoE+
£141.65
Excl.VAT
81 in stock
Shipping & Delivery
-
Standard delivery
Our courier will deliver to the specified address
3-4 Days
From £9.95
-
Express delivery
All heavy items above 25kg will be charged shipping cost as per actual
1-2 Days
From £14.95
60 Gbps, Forwarding Rate 45 Mpps, Supported VLANs 256, AC/DC, external, 15W
Certificates
| Compliance certificates | CE, Federal Communications Commission (FCC), Industry Canada (IC) |
|---|
Data transmission
| Forwarding rate | 45 Mpps |
|---|---|
| Jumbo frames support | Yes |
| MAC address table | 4000 entries |
| Switching capacity | 60 Gbit/s |
| Throughput | 30 Gbit/s |
Design
| DIN rail mounting | Yes |
|---|---|
| Form factor | Desktop/Wall-Mounting |
| Housing material | Polycarbonate (PC) |
| LED indicators | Activity, Link, Power, Status |
| Product colour | White |
| Wall mountable | Yes |
Management features
| Switch layer | L2 |
|---|---|
| Switch type | Managed |
Multicast features
| Multicast support | Yes |
|---|
Network
| 10G support | Yes |
|---|---|
| Broadcast storm control | Yes |
| Ethernet LAN data rates | 10, 100, 1000, 2500 |
| Flow control support | Yes |
| Number of VLANs | 256 |
| Port mirroring | Yes |
| Rate limiting | Yes |
| VLAN support | Yes |
Operational conditions
| Operating relative humidity (H-H) | 10 - 90 % |
|---|---|
| Operating temperature (T-T) | -20 - 45 °C |
Ports & interfaces
| 10G Ethernet (copper) ports quantity | 1 |
|---|---|
| 2.5G Ethernet (copper) ports quantity | 8 |
| Basic switching RJ-45 Ethernet ports quantity | 8 |
| Basic switching RJ-45 Ethernet ports type | 2.5G Ethernet (100/1000/2500) |
| Power connector | DC-in jack |
| SFP+ module slots quantity | 1 |
Power
| DC input voltage | 54 V |
|---|---|
| Input current | 3.9 A |
| Power consumption (max) | 17 W |
| Power source | PoE/USB |
| Power supply included | No |
Power over Ethernet (PoE)
| Power over Ethernet (PoE) | No |
|---|---|
| Power over Ethernet plus (PoE+) ports quantity | 1 |
Security
| Loop protection | Yes |
|---|
Vendor information
| Brand Name | Ubiquiti |
|---|---|
| Warranty | 2 Year(s) |
