L2+ 24-Port 100/1000X SFP + 8-Port Shared TP + 4-Port 10G SFP+ Managed Switch

Name: L2+ 24-Port 100/1000X SFP + 8-Port Shared TP + 4-Port 10G SFP+ Managed Switch
Brand: Planet
SKU: GS-5220-16S8CR
Price: 386.93 GBP
Availability: InStock

£386.93

Excl.VAT

SKU: GS-5220-16S8CR Category: Managed Switches Brand: Planet

12 in stock

Add to compare

Add to wishlist

Add to compare

Add to wishlist

Shipping & Delivery

Standard delivery

Our courier will deliver to the specified address

3-4 Days

From £9.95

Express delivery

All heavy items above 25kg will be charged shipping cost as per actual

1-2 Days

From £14.95

L2+ 24-Port 100/1000X SFP + 8-Port Shared TP + 4-Port 10G SFP+ Managed Switch

PLANET GS-5220-16S8CR is a Layer 2+ Managed Gigabit Switch which provides high-density performance and supports Layer 3 static routing with 10Gbps uplink and multiple SFP fiber interfaces delivered in a 1U rugged case design. The administrator can flexibly choose the suitable SFP/SFP+ transceiver according to the transmission distance or the transmission speed required to extend the 10G network efficiently. Besides, with 128Gbps switching fabric, the GS-5220-16S8CR can handle extremely large amounts of data in a secure topology linking to backbone or high capacity servers for ISP and enterprise VoIP, video streaming, and multicast applications.

Certificates

Certification	FCC Part 15 Class A, CE

Data transmission

Jumbo frames	10000
Jumbo frames support	Yes
MAC address table	16000 entries
Number of static routes	128
Packet buffer memory	16 MB
Static route	Yes
Store-and-forward	Yes
Switching capacity	128 Gbit/s
Throughput	95.23 Mpps

Design

Form factor	1U
Housing material	Metal
LED indicators	Yes
Number of fans	2 fan(s)
Product colour	Blue
Rack mounting	Yes
Reset button	Yes
Stackable	No

Management features

ARP inspection	Yes
Cloud-managed	Yes
Quality of Service (QoS) support	Yes
Switch layer	L2+
Switch type	Managed
System event log	Yes
Traffic classification	Yes
Traffic shaping	Yes
Web-based management	Yes

Multicast features

Multicast support	Yes
Number of multicast groups filtered	255

Network

10G support	No
Auto MDI/MDI-X	Yes
Auto-negotiation	Yes
Broadcast storm control	Yes
Copper ethernet cabling technology	1000BASE-T, 100BASE-T, 10BASE-T
Ethernet LAN data rates	10, 100, 1000
Flow control support	Yes
Full duplex	Yes
Half duplex	Yes
IP routing	Yes
Link aggregation	Yes
MAC address auto-aging supported	Yes
MAC address auto-learning supported	Yes
Networking standards	IEEE 802.1ab, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Number of VLANs	4094
Port mirroring	Yes
Rate limiting	Yes
Spanning tree protocol	Yes
VLAN support	Yes
Virtual LAN features	IP subnet–based VLAN, MAC address-based VLAN, Multicast VLAN, Private VLAN, Protocol-based VLAN, Tagged VLAN, Voice VLAN

Operational conditions

Heat dissipation	102.9 BTU/h
Operating relative humidity (H-H)	5 - 95 %
Operating temperature (T-T)	0 - 50 °C
Storage relative humidity (H-H)	5 - 95 %
Storage temperature (T-T)	-10 - 70 °C

Optical fiber

Fiber ethernet cabling technology	1000BASE-X, 100BASE-X

Packaging data

AC adapter included	Yes
Cables included	RS-232
Mounting brackets included	Yes
Quick start guide	Yes
Rack mount kit	Yes
Rubber feet	Yes

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity	8
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Combo SFP ports quantity	8
Compatible memory cards	Not supported
Console port	RS-232
Fiber optic connector	SFP
Fiber ports quantity	24
Installed SFP modules quantity	24
Installed SFP+ modules quantity	4
SFP module slots quantity	24

Power

AC input frequency	50 - 60 Hz
AC input voltage	100 - 240 V
DC input voltage	36 - 72 V
Input current	0.6 A
Power consumption (max)	45 W
Power consumption (typical)	36.2 W
Power supply included	Yes
Redundant power supply (RPS) support	Yes

Power over Ethernet (PoE)

Power over Ethernet (PoE)	No
Power over Ethernet (PoE) ports quantity	8
Power over Ethernet plus (PoE+) ports quantity	8

Protocols

Management protocols	SNMP,SSH,SSL/TLS

Security

Access Control List (ACL)	Yes
Authentication	MAC-based authentication, Port-based authentication
Authentication type	RADIUS, TACACS+
BPDU filtering/protection	Yes
DHCP features	DHCP relay, DHCP snooping
IGMP snooping	Yes
Loop protection	Yes
MAC address filtering	Yes
Queue scheduling algorithms	SP, Weighted Round Robin (WRR)
SSH/SSL support	Yes
Security algorithms	SNMPv3, SSH, SSL/TLS

Vendor information

Brand Name	Planet
Homepage	https://www.planet.com.tw/en/product/gs-5220-16s8cr-v2
Warranty	3 Year(s)
